Small and Large Animal Solutions




BMV BPU90 System



BMV BPU90 Color Doppler Veterinary Ultrasound

Simple operation; clear image; stability; reliability, rich functions, high cost performance and strong mobility.

Technology platform with Excellent performance, stability and reliability

Powerful Data Management System

Advanced imaging technology, excellent, excellent image quality

Appearance design conforming to ergonomic

Comprehensive clinical application solutions

BMV BPU60 High-Performance Portable Colour Doppler Ultrasound Diagnosis System


The BMV BPU60 Vet is based on the brand-new Cutting-edge platform, equipped with a new generation of multi-crystal probes, with advanced imaging technology, rich clinical application software, humanized appearance design and intimate human-computer interaction, enabling veterinarians to integrate in the clinical diagnosis process Attention is all focused on the animals themselves, providing veterinarians with high-quality images and a full range of clinical solutions, which can not only meet the daily clinical diagnosis needs of veterinarians, but also take into account various applications such as teaching and research.

   BMV BPU60 VET Angled

  BMV MX9 Wireless Ultrasound




BMV MX9 Wireless Ultrasound

MX9 Scanners, with enhanced image quality based on our iBTech+ platform, premium probe technology and advanced beamforming, is designed to provide trustworthy imaging at any mobile clinical environment for clinicians, rendering more confidence on diagnosis.

BMV BestScan® S4

Innovative and Distinctive Design, User-centric design, and easy to use.

  • Fully sealed unit with waterproof design, for effortless cleaning;
  • All-in-on design with high quality chemical resistance materials, for reliable disinfection to help maintain biosecurity standards;
  • The first RFID vet wireless ultrasonic system in the world;
  • Revolutionary iBTech+ platform, offering enhanced image quality and larger scan angel;
  • Total broadband wireless connected, steady and easy-to-use dedicated workflow, abundant accessories;
  • S4 and S3 Plus support farmers from easy pregnancy detetion and backfat mesure to report exported to Connect!Vet Cloud.


 BMV S4 Portable System

BMV S3 Plus Ultrasound Probe



BMV S3 Plus

The BMV S3 Plus is a general-use hand-held software-controlled wireless veterinary ultrasound scanner designed for pigs, sheep or goats. It obtains real-time ultrasound signals through WiFi and reflects them on Android devices like smart phones or tablet PCs







Probes and Transducer Types


BMV 3C6C Colour Doppler Convex Array Probe/Transducer for BPU Range


Applications: Abdominal, Gynecology, Nerve, Musculoskeletal, Obstetrics
Frequency Bandwidth: 2.5-6MHz
Central Frequency: 3.5MHz
Radius: 60 mm
View Angle: 61 degrees
Scanning Depth: 36-351 mm
Elements: 128
 ultrasound probe


BMV 6C15C Colour Doppler Micro Convex Array Probe/Transducer


Applications:
  • Small animal scanning - Critical care, Cardiac, Abdominal
  • Large animal scanning - Cardiac, difficult to image areas, etc
Frequency Bandwidth: 5.0/6.5/8.0/H9.0MHz
Centre Frequency: 6.5 MHz
Radius: 15 mm
View Angle: 100.7 degrees
Scanning Depth: 36~184 mm
Elements: 128
Biopsy guide available
 6C15C ultrasound probe


BMV 7L4C Colour Doppler Linear Array Probe/Transducer for BPU Range


Applications:
  • Small animal scanning - Critical care, abdominal
  • Equine scanning - Tendon
Frequency Bandwidth: 6.5/7.5/8.5/H9.0/H10.0MHz
Centre Frequency: 7.5MHz
Scanning Width: 40 mm
Scanning Depth: 18~184 mm
Elements: 128
Biopsy guide available
 7L4C ultrasound probe


BMV 8L4C Colour Doppler High Frequency Linear Probe/Transducer for BPU Range


Applications:
  • Small animal scanning - Critical care, abdominal, etc,
  • Equine scanning: Tendons
Frequency Bandwidth: 5.0/8.5/12.0/H10.0/H11.0MHz
Centre Frequency: 8.5MHz
Scanning Width: 40 mm
Scanning Depth: 10~120 mm
Elements: 128
Biopsy guide available
 8L4C ultrasound probe


BMV 6I7C Colour Doppler Rectal Linear Probe/Transducer


Application: Large Animals Reproductive, Equine Tendon
Frequency Bandwidth: 4.5/6/7.5/H8.0/H9.0 MHz
Centre Frequency: 6.0 MHz
Scanning Width: 70 mm
Scanning Depth: 18~184 mm
Elements: 128
 6I7C ultrasound probe
