WD Ultrastar Enterprise 3.5" SATA
Description
Western Digital Ultrastar Enterprise Series
Let Your Data Thrive with Ultrastar Quality, Capacity, and Power Efficiency
Delivering highly dependable performance to any storage environment, Ultrastar hard drives are designed for demanding workloads (up to 550TB per year), 10 times the workload rating of desktop drives. Ultrastar drives employ advanced technologies for enterprise-class reliability and power efficiency, to deliver a lower
total cost of ownership, so you can safeguard more of your valuable data. The Ultrastar family delivers a long-standing tradition of reliability with an unbeaten 5-year limited warranty. Western Digital is dedicated to providing a complete portfolio of hard drives to create environments for your data to thrive..
Highlights
- Our most popular Ultrastar SATA models
- Full range of capacities (1TB to 14TB)
- High workload rating, 10X higher than desktop drives, for 24x7 operation
- Advanced technology design supports enterprise-class reliability and power efficiency
- 6 Gb/s SATA
- 5-year limited warranty
Applications and Workload
- Cloud applications and distributed file systems like Apache Hadoop® to support Big Data analytics
- Bulk storage using Object storage solutions like Ceph™ and OpenStack Swift
- Direct & Network Attached Storage (DAS & NAS), RAID storage
- Industrial or Surveillance Applications
- Entry Server Storage
Capacities Available
- 1 TB
- 2 TB
- 4 TB
- 6 TB
- 8 TB
- 10 TB
- 12 TB
- 14 TB
Product Specifications
- Interface SATA 6 Gb/s
Performance Specifications
- Rotational Speed 7,200 RPM (nominal)
- Buffer Size 600MB
- Load/unload Cycles 600,000 minimum
Transfer Rates
Buffer To Host (Serial ATA) 6 Gb/s (Max)
Physical Specifications
- Capacity 1/2/4/6/8/10/12/14 TB
- Form Factor 3.5 Inch
Metric
- Height 26.1 mm
- Depth 147 mm
- Width 101.6 mm
Environmental Specifications
- Operating Shock (Read) 70G, 2 ms
- Non-operating Shock 300G, 2 ms
Acoustics
- Idle Mode 20/25/29/34 dBA (average)
- Seek Mode 0 28/36/38 dBA (average)
- Seek Mode 3 28/36/38 dBA (average)
Temperature (Metric)
- Operating 5° C to 60° C
- Non-operating -40° C to 70° C
Electrical Specifications
- Current Requirements
- Power Dissipation
- Read/Write 6.0/6.9/9.2/8.8/7.0/8.1 Watts
- Idle 5.0/5.5/5.9/7.4/8.0/ Watts
- Standby 0.4/0.8/0.9/1.4/2.9 Watts
- Sleep 0.4/0.8/0.9/1.4/2.9 Watts
Compatibility
- Operating System Compatibility: Windows/Mac
Warranty
- 5 Years
