IMAGE Information Systems iQ-ROUTER Image Compression, Teleradiology and Workflow Management Software


Compresses and transmits DICOM image data to significantly speed up DICOM transmissions and to enable the use of low cost internet lines for speedy teleradiology; transmits image data and search requests in both directions; individual patient information can be pseudonymized or encrypted according to data protection laws; solves incompatibility issues between different modalities by virtually supporting all DICOM image formats and transfer syntaxes. Defined DICOM header data can be added, modified or deleted; includes workflow management features; integrated forward manager receives data via DICOM STORE, analyzes the data according to predefined criteria and then sends the datasets to flexibly defined destinations; workflows in many environments can be automated and facilitated. DICOM character sets can be automatically converted into Unicode (ISO IR 192). Includes Perl Script Language to configure complex change rules.

Three editions - tailored to your needs


Choose the edition that best fi ts the size and conditions of your medical network, depending on the number of stations
you need to connect and the number of data adjustments you plan to implement.

iQ-ROUTER
This version is ideally suited for small imaging centers with a low number of imaging devices.
Connect up to 2+1 DICOM nodes. Apply up to 5 attribute rules (for small imaging centres with a low number of imaging devices).

iQ-ROUTER PRO 10
This version perfectly meets the requirements of mid-sized imaging centres and small hospitals.
Connect up to 10+1 DICOM nodes. Apply up to 25 attribute rules (for small to medium imaging centres with a medium number of imaging devices).

iQ-ROUTER PRO 20
This version perfectly meets the requirements of mid-sized imaging centres and small hospitals.
Connect up to 20+1 DICOM nodes. Apply up to 25 attribute rules (for small to medium imaging centres with a medium number of imaging devices).

iQ-ROUTER PREMIUM 100
This version is intended as central image distribution node for imaging centre groups, VNA and large hospitals.
Connect up to 100+1 DICOM nodes. Apply up to 250 attribute rules

iQ-ROUTER PREMIUM 200
This version is intended as central image distribution node for imaging centre groups, VNA and large hospitals.
Connect up to 200+1 DICOM nodes. Apply up to 500 attribute rules

iQ-ROUTER PREMIUM 300
This version is intended as central image distribution node for imaging centre groups, VNA and large hospitals.
Connect up to 300+1 DICOM nodes. Apply up to 750 attribute rules

General
- Runs without user login (NT service controlled by the OS)
- Flexible logging, monitoring and configuration tool

DICOM SUPPORT
- DICOM store, query/retrieve, verification
- Support of all DICOM-defined "specific character sets" including Asian languages and unicode UTF-8
- Fully parallel processing (multi-threaded)
- Support of all DICOM store classes including non-image classes like Structured Reports
- Unlimited number of parallel connections and modalities within the network

Routing/Enhanced DICOM
- Transparent routing of all requests
- Bidirectional DICOM-interface
- Patient root and study root model support for DICOM queries

Security/Privacy
- Transport Layer Security (TLS/SSL) support
- Flexible service access control for all modalities within the network
- Restriction for query requests
- Automatic pseudonymization of patient data

Teleradiology
- Proprietary Wavelet compression
- JPEG-LS standard
- JPEG/JPEG 2000 lossy and lossless compression
- Runtime Length Encoding (RLE) lossless compression
- Adjustable compression ratio for all lossy compressions
- Support for long latency time and low bandwidth connections, e.g. satellite lines
- Supports VPN, dynamic IPs and fire walling

Workflow
- New rule set for enhanced DICOM attribute manipulation (NEW!)
- Automatic correction of forwarded objects compliant to the DICOM standard
- Automatic changes of AE titles (AE mapping)

Operating Systems
- Windows 10, Windows 11, Windows Server 2019

Languages
- Unicode support

Certification
- CE, FDA 510(k), TGA

iQ-ROUTER PRO Features


DICOM Support
- Rule-based modification of DICOM attributes
- Definable conditions to set the rules: attributes, AE title source (calling AE),
- AE title destination (called AE)
- Possible modifications of attributes: add, replace, copy, delete, add prefix or suffix

Teleradiology
- Regular Expressions for fully automatic correction of any image and data errors or DICOM inconsistencies (NEW!)

Work flow
- Automatic rule-based forwarding of DICOM data to multiple destinations
- Definable conditions to set the rules: attributes, AE title source, AE title destination, day of the week, hour
- New rule set for enhanced DICOM attribute manipulation (NEW!)
- Asynchronous forward management (multi-threaded)

Forward Management
- Support of multiple conditions for each rule
- Support of wildcards for all text fields in rules and conditions
- Supports forwards based on called or calling AE title, time or day of the week and any DICOM header information for rules and conditions

iQ-ROUTER PREMIUM Features
Communication / Interfacing
- Possible customization of the interaction with available medical information systems
- Patient data validation for consistency consulting local databases
- HL7 triggered routing of DICOM data sets

Data Consistency
- Import Workflow Patient Reconciliation using HL7 and Master Patient Index (MPI)
- Extraction of measurements from DICOM data in Structured Reports (NEW!)

Licensing
- On request

IMAGE Information Systems iQ-ROUTER Image Compression, Teleradiology and Workflow Management Software


License model: one software license per computer
Trial license: time-limited (15 days in iQ-ROUTER PRO mode, additional 15 days in iQ-ROUTER BASIC mode)
Warranty: 1 year limited warranty
Activation method: fingerprint/software activation keys
Languages: English
Annual Service Package: mandatory (see Warranty and Service Packages for details)
