IMAGE Information Systems iQ-WORKLIST
Consistent Data Throughout RIS and PACS
iQ-WORKLIST is a powerful DICOM worklist server and a must-have in every imaging centre
DICOM worklists are indispensable in a radiological environment, as they accelerate the modality work flow and ensure that typing errors are avoided. Through their use, consistent data is maintained throughout all medical imaging systems.
iQ-WORKLIST can interface with virtually any radiology, practice or hospital information system, read scheduling data, and create DICOM work lists for imaging modalities.
In addition, it can read HL7 order requests (ORM/OMG), patient update/ merge messages (ADT), and also accepts BDT/GDT or structured text files as a data source.
iQ-WORKLIST can be easily installed and configured due to the included configuration presets. It is reliable and easy to maintain. For special circumstances, iQ-WORKLIST offers PACS administrators a powerful mapping tool for data conversion between various standards.
Three versions are available to meet all of your connection needs:
iQ-WORKLIST 2
for a maximum of 2 modalities
iQ-WORKLIST 5
for a maximum of 5 modalities
iQ-WORKLIST PRO
for a maximum of 10 modalities
iQ-WORKLIST PREMIUM
for an unlimited number of modalities
Also includes an ADT module for patient reconciliation support.
iQ-WORKLIST
FULLY AUTOMATED WORK FLOW
iQ-WORKLIST can read procedure information from connected modalities, such as radiation dose, billing data, study status, series, or image data, and provide it to the feeding information system like HIS, RIS or EMR. This is possible through MPPS (Modality Performed Procedure Steps) which enables iQ-WORKLIST to accept messages for creating, modifying, and returning MPPS information.
SUPERIOR PERFORMANCE
iQ-WORKLIST 2.0 uses an SQL database which increases its performance and results in more efficient data processing. It can be employed flexibly in both small imaging centres and big hospitals. Because it processes incoming messages and simultaneous worklist queries using multi-threads, iQ-WORKLIST can also be used centrally for large multi-site projects.
COMPATIBILITY
Many information systems lack an HL7 interface. By using iQ-WORKLIST, virtually any information system can be connected using freely configurable text files. In addition, iQ-WORKLIST provides Unicode support (UTF-8) and thus speaks all major world languages. Local character sets can be automatically converted to Unicode.
iQ-WORKLIST supports the following C-FIND Query and Retrieve tags. (A complete list can be found in the iQ-WORKLIST 2.0 DICOM Conformance Statement):
Patient
- patient's Name, Patient ID, patients Birth Date, patient's Sex, patient's Weight, patient State (NEW!)
- Pregnancy Status (NEW!)
- Medical Alerts (NEW!)
- Additional Patient History
- Allergies
- Special Needs (NEW!)
Visit
- Admission ID (NEW!)
- Current Patient Location (NEW!)
Study
- Accession Number
- Requesting Physician
- Referring physicians Name (NEW!)
- Requesting Service (NEW!)
- Requested Procedure ID, Requested Procedure Description
- Study Instance UID
- Requested Procedure Priority
- Patient Transport Arrangements (NEW!)
- Scheduled Station AE Title
- Scheduled Procedure Step Start Date and Start Time
- Modality
- Scheduled Performing physicians Name
- Scheduled Procedure Step Description
- Scheduled Station Name
- Scheduled Procedure Step Location
- Scheduled Protocol Codes (NEW!)
- Scheduled Procedure Step ID (NEW!)
iQ-WORKLIST BASIC/PRO Work Flow
1. The patient is registered to a RIS, HIS, PMS, or any other medical information system (MIS).
2. The MIS sends scheduling data to the iQ-WORKLIST server.
a) as an HL7 order
b) as a GDT order
c) as a text file
3. iQ-WORKLIST collects the scheduling information in a local database and provides a DICOM worklist to any imaging modality.
4. The imaging modalities query the worklist manually or automatically to get accurate patient and scheduling information.
5. The imaging modalities query the worklist manually or automatically and send status information back to iQ-WORKLIST.
6. iQ-WORKLIST forwards the status information to the medical information system:
a) answering the HL7 order request
b) answering the GDT order request
c) in response to the text file
iQ-WORKLIST PREMIUM Work Flow
In Addition to IQ-WORKLIST BASIC/PRO Work flow
7. The MIS sends an ADT message to iQ-WORKLIST, e.g. in case the patient information is unknown during initial imaging.
8. iQ-WEBX queries iQ-WORKLIST in order to reconcile patient demographics after the identity of the patient is known or has changed.
9. The imaging modalities query the worklist manually or automatically to get accurate patient and scheduling information.
iQ-WORKLIST Features
General
- Runs as an NT service in the background
- Includes several logging levels and files for documentation and easy error tracking (NEW!)
- Fully automated workflow through MPPS (Modality Performed Procedure Steps) (NEW!)
- SQL database for enhanced performance and scalability (NEW!)
- Higher compatibility through Unicode support for virtually all languages, a customizable text parser, and an extended list of supported worklist search keywords (NEW!)
- Application and event acknowledgement support (NEW!)
- Message syntax dictionary (NEW!)
Input
- Reads HL7 order messages (ORM, OMG); (Refer to HL7 Conformance Statement for detailed information) (NEW!)
- Reads BDT/GDT data
- Reads study data from structured text files
- Processes multiple sources (HL7/BDT/Text) concurrently
- Compatible to HL7 2.x
- Maps files using regular expressions to adapt BDT/GDT/Text file dialects
- Maps HL7 files using message fields
- HL7 network and file message listener
- Customizable actions based on incoming messages (NEW!)
- Support of multiple orders in a single order message (NEW!)
DICOM
- Serves up to two devices (DICOM WORKLIST SCU nodes)
- DICOM worklists based on scheduling data
- Creates unique Study Instance UIDs for the querying modalities
- Accession numbers can be created based on time stamps or incremented IDs
- Compatible with any DICOM worklist client
- Supports any modality queries, e.g. by patient name, patient ID, birth date, modality, scheduled station AE title, scheduled procedure start time and date
iQ-WORKLIST PRO Features
DICOM
- Serves up to 10 devices (DICOM WORKLIST SCU nodes)
iQ-WORKLIST PREMIUM Features
DICOM
- Serves an unlimited number of devices
Input
- Reads HL7 ADT
IMAGE Information Systems iQ-WORKLIST
iQ-WORKLIST 2 & 5
License model: one software license per worklist server
Trial license: time-limited (30 days in iQ-WORKLIST PRO mode)
Warranty: 1 year limited warranty
Activation method: fingerprint/software activation key
Languages: English
iQ-WORKLIST PRO
License model: one software license per worklist server
Trial license: time-limited (30 days)
Warranty: 1 year limited warranty
Activation method: fingerprint/software activation key
Languages: English
iQ-WORKLIST PREMIUM
License model: one software license per worklist server
Trial license: time-limited (30 days); only available upon request
Warranty: 1 year limited warranty
Activation method: fingerprint/software activation key
Languages: English
